Wireless Power

EPC Wireless Power Solutions – Multiple Device, Large-Surface-Area Power Made Easy

Wireless power is ready to be incorporated into our daily lives. Transmitters can be placed in furniture, walls, floors, to efficiently and economically power or charge our electronic and electrical devices over large areas and to multiple devices.

Magnetic resonance technology is the key to ubiquitous implementation – enabling large surface area transmission, spatial freedom for placement of receiving devices, and the ability to power multiple devices simultaneously.

Request WiPo Technology ebooklet

Wireless Power Publications

Find a Solutions Provider

Choose an eGaN FET or IC

Choose a Development Kit

Request Design Assistance from a Wireless Power Expert

Total System Efficiency

Video Gallery

The Future of Wireless Charging | Panel at CCNC 2021 with Alex Lidow

EPC at CES 2018 and the future of Wireless Charging

Reuters' Jane Lanhee Lee interviews EPC and takes a look at the future of Wireless Charging.

EPC Reveals 300 W GaN-Based Wirelessly Powered Smart Desk at CES

Reduce Time to Market – Wireless Power System Demonstration Kits

EPC offers a full range of transmit and receive reference designs from single device charging to multiple devices powered simultaneously across a large surface area.

At the core of these EPC reference designs are eGaN^® FETs and ICs operating at 6.78 MHz frequency (meeting the AirFuel Alliance standard) resulting in maximum wireless power system efficiency.

GaN enables high efficiency for both the low frequency (Qi) and high frequency (AirFuel) standards supporting a lower cost, single transmit amplifier solution that can wirelessly charge devices regardless of the standard used in the receiving device.

All EPC wireless power demonstration kits contain a transmit unit (wireless power amplifier and transmit coil) and device receive unit(s). In addition, power amplifiers and device receive units are available to purchase individually.

		Device Receive Unit
		EPC9513 Category 3 (6.5 W)	EPC9513 Category 3 (6.5 W) EPC9515 Category 4 (13 W)	EPC9513 Category 3 (6.5 W) EPC9514 Category 5 (27 W)	Category 3 (6.5 W) Qi (5 W)
	Typical Application	smart phone, Digital Assitant, any 1 A USB device	tablet, any 2 A USB device	small form factor laptop, 19 V lamp	smart phone, Digital Assitant, any 1 A USB device
Transmit Unit (amplifier)	EPC9510 Class 2 (10 W)	EPC9127 Class 2 Demo Kit
	EPC9509 Class 3 (16 W)		EPC9128 Class 3 Demo Kit
	EPC9512 Class 4 (33 W)			EPC9129 Class 4 Demo Kit
	EPC9511 Multi-Mode (10 W)				EPC9121 Multi-Mode Demo Kit

EPC9128, 16 W Class 3 kit

The kits cover power levels ranging from AirFuel class 2 through AirFuel class 4 as well as a multi-mode demo kit that covers both the AirFuel class 2 as well as the Qi inductive standard in a single amplifier.

Wireless Power Amplifiers

Amplifier boards are available for customers that have their own coil design.

	AirFuel Class	Power Level	Power Amplifier Board	Topology
Transmit Power (amplifier)	2	10 W	EPC9510	ZVS Class D
	2	10 W	EPC9051	Class E
	3	16 W	EPC9509	ZVS Class D
	3	16 W	EPC9052	Class E
	4	33 W	EPC9512	ZVS Class D
	4	33 W	EPC9053	Class E
	5	60 W	EPC9065	ZVS Class D
	5	60 W	EPC9083	Class E
	Multi-Mode	10 W (AF) 5 W (Qi)	EPC9511	ZVS Class D

EPC9512 Amplifier Board

Device Receive Units

Device receive units are now available for customers that want to get various consumer electronic products quickly to market.

	AirFuel Category	Power Level	V_OUT	I_OUT	Device Receive Board	Example Application
Device Receive Unit	3	5 W	5	1	EPC9513	smart phone
	4	10 W	5	2	EPC9515	tablet, phablet
	5	27 W	19	1.4	EPC9514	laptop

EPC9513 Receive Unit

Examples of Device Receive Coils

Personal assistant
(5 V, 5 W)

Office desk lamp
(12 V, 6 W)

Computer monitor
(100 V, 22W)

eGaN FETs and ICs for Wireless Power

EPC’s gallium nitride devices are ideal for wireless power due to their ability to operate efficiently at high frequency, deliver high power, and in a small, low profile footprint.

With their low capacitance, zero reverse recovery, and low on-resistance, eGaN FETs and ICs ensure low operating losses leading to higher amplifier efficiency and help keep EMI generation low.

Part Number	Configuration	V_DS	Max R_DS(ON) (mΩ) (V_GS = 5 V)	Max Peak Pulsed I_D(A) (25°C, Tpulse = 300µs)	Package (mm)	Wireless Power Function
EPC2108	Dual with Bootstrap	60	240 240 3300	5.5 5.5 0.5	BGA 1.35 x 1.35	Main power stage in amplifier
EPC2219	AEC-Q101 Single with Gate Diode	65	3300	0.5	BGA 0.9 x 0.9	Synchronous bootstrap in amplifier
EPC2107	Dual with Bootstrap	100	390 390 3300	3.8 3.8 0.5	BGA 1.35 x 1.35	Main power stage in amplifier
EPC2038	Single with Gate Diode	100	3300	0.5	BGA 0.9 x 0.9	Synchronous bootstrap in amplifier
EPC2037	Single	100	550	2.4	BGA 0.9 x 0.9	Main power stage in amplifier / Synchronous bootstrap in amplifier
EPC8010	Single	100	160	7.5	LGA 2.1 x 0.85	Main power stage in amplifier
EPC2036	Single	100	73	18	BGA 0.9 x 0.9	SEPIC pre-regulator
EPC2007C	Single	100	30	40	LGA 1.7 x 1.1	Main power stage in amplifier
EPC2115	Dual with Integrated Driver	150	88	18	BGA 2.9 x 1.1	Main power stage in amplifier
EPC2012C	Single	200	100	22	LGA 1.7 x 0.9	Main power stage in amplifier
EPC2019	Single	200	50	42	LGA 2.8 x 0.95	Main power stage in amplifier / Boost FET in receive circuit
EPC2112	Single with Integrated Driver	200	40	40	BGA 2.9 x 1.1	Main power stage in amplifier

EPC Gallium Nitride FETs for Wireless Power Applications

The technological capability to achieve a wireless power future is here today!

Wireless Handbook

A major challenge for implementing wireless power is the design of the amplifier. The aim of this handbook is to understand the many challenges to designing an amplifier for wireless power, such as radiated EMI, multi-mode systems, and ways to improve efficiency.

Trilogy of Wireless Power Transfer

The "Trilogy of Wireless Power Transfer" consists of three parts: Basics Principles of Wireless Power Transmission, Wireless Power Transfer Systems and Applications. The book costs 19 euros and can be ordered from Würth Elektronik eiSos or through bookstores.
